ZE08 CH2O Formaldehyde Gas Sensor Module

ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
-45 %
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
ZE08 CH2O Formaldehyde Gas Sensor Module
₹763
₹1,379

(inc GST)

  • Stock: In Stock
  • ₹7 FlyRobo Cashback.
  • SKU: FR-01-153
    5 or more ₹742
    15 or more ₹731

ZE08-CH2O utilizes the electrochemical principle to detect CH2O in the air which makes the module with high selectivity and stability. It has a built-in temperature sensor to make temperature compensation. It has the digital output and analog voltage output at the same time.

Features:

  • Model: ZE-08 CH2O
  • High sensitivity and resolution.
  • Low power consumption.
  • Good stability, excellent ability of anti-interference, and excellent Linear output
  • Application: It has some applications such as portable detector, air-quality monitor, air cleaner, air renewal system, air conditioner, and smart home.

Package Includes:

1 x ZE08 CH2O Formaldehyde Gas Sensor Module.



Technical
Model

ZE-08 CH2O

Cable Length

15 cm

Detection Gas

Formaldehyde

Interference Gas

Alcohol, Carbon monoxide, etc.

Operating Humidity Range

15% RH - 90% RH

Operating Voltage

3.7V to 5.5V

Range

0 to 5 ppm

Recovery Time

≤60 seconds

Resolution

≤0.01ppm

Response Time

≤60 seconds

Storage temperature

0 to 25℃

Working temperature

-20℃ to 50℃

Length

25.76 mm

Height

8 mm

Width

23 mm
