L298N 2-way Dual H-Bridge DC Driver Module

L298N 2-way Dual H-Bridge DC Driver Module
L298N 2-way Dual H-Bridge DC Driver Module
L298N 2-way Dual H-Bridge DC Driver Module
L298N 2-way Dual H-Bridge DC Driver Module
L298N 2-way Dual H-Bridge DC Driver Module
L298N 2-way Dual H-Bridge DC Driver Module

L298N 2-way Dual H-Bridge DC Driver Module
₹89

(inc GST)

  • Stock: In Stock
  • SKU: FR-04-536

L298N 2-way Dual H-Bridge DC Driver Module can drive two DC motors or 4-wire 2-phase stepper motors and achieve forward rotation or reverse rotation. It is possible to adjust the rotation speed. Each can provide a continuous current of 1.5A, peak current can be up to 2.5A, has thermal protection, and can be automatically restored.

Features:

  • Suitable for battery-powered smart cars, toy cars, robots, etc.
  • A Dual H-bridge motor driver can drive two DC motors or a 4-wire two-phase stepper motor.
  • Support forward/reverse rotation and speed regulation function.
  • Single operating current 1.5A, peak current up to 2.5A, low standby current (less than 0.1uA).
  • Built-in common conduction circuit.
  • Built-in thermal protection circuit.

Package Includes:

1 x L298N 2-way Dual H-Bridge DC Driver Module.

Technical
Continuous current

1.5A

Peak Current

2.5A

Signal Input Voltage

1.8 - 7V

Supply Voltage

2 - 10V

Length

25 mm

Height

8 mm

Width

20 mm
