Type-C 5V-30V Delay Relay Module - Cyclical Timing Circuit Switch with Power-Off Delay

This versatile Type-C Relay Module is a multi-function timing controller designed for industrial and hobbyist automation. Supporting a wide voltage range of 5V to 30V, and featuring a convenient Type-C USB interface, it allows users to program precise timing delays and cyclical switching patterns. The module supports multiple operating modes, including trigger-start delays, infinite loop cycles, and delayed power-off functions. With its integrated LCD/LED display and four-button programming interface, setting time intervals from 0.1 seconds up to 999 minutes is intuitive and precise. The onboard optocoupler isolation ensures that trigger signals remain clean and protected from the high-power relay switching noise, while the emergency STOP button provides immediate manual control. Ideal for fan timers, battery charging limiters, and automated test equipment.

Key Features:

• Cyclical Timing Modes: Program infinite 'ON/OFF' loops for automated equipment testing and irrigation.
• Type-C Power Interface: Modern 5V USB-C input simplifies power for desktop and portable projects.
• Wide 5V-30V Support: Terminal inputs allow for direct connection to 12V and 24V vehicle and industrial systems.
• One-Key STOP Function: Instant relay disconnect button for enhanced safety and troubleshooting.
• Sleep Mode Power Saving: Display automatically turns off after 5 minutes of inactivity to conserve energy.
• Optocoupler Isolation: High-grade signal isolation prevents interference between control and load circuits.

Package Includes:

1 x Type-C 5V-30V Delay Relay Module - Cyclical Timing Circuit Switch with Power-Off Delay
