Tarot 3 Axis Gimbal T4-3D Dual Shock Absorber PTZ for Gopro Hero4 3+ 3 FPV RC Drone TL3D02

The Tarot T4-3D 3 axis, self stabilized gimbal is a professional camera mount for aerial videographers and photographers who want quality and performance. It has a lightweight, durable aluminum, carbon fiber and plastic structure that will provide outstanding stability and control for any aerial camera operations even in severe environments. The Tarot T4-3D gimbal is designed for GOPRO HERO3 / HERO4 and similar cameras and can be used with multi-copters, fixed-wing airplanes and helicopters. It is equipped with an independent IMU module and has a "point follow" mode (PF) and a first-person view (FPV) mode. The innovative design allows complete control over the camera. Joystick movement speed is correspondingly linked to camera axis speed, so the faster you move the joystick the faster the axis will move. All the power and signal wires are embedded in the structure and the firmware is upgradeable through the PC interface.

• Brand Name: Tarot
• Item Name: T4-3D 3 Axis Gimbal
• Item NO.:TL3D02
• Input power: LiPo 2S~6S battery
• Angle control accuracy: + 0.02
• Maximum controllable speed:
• Pitch direction (TILT): + 200 degree /s
• Controllable rotation range
• Pitch direction (TILT):-120 degrees to +15 degrees
• Working current: 30mA (@25V) 50mA (@12V)
• Locked rotor current: 350mA (@25V) 700mA (@12V)
• Working environment temperature: -20 degrees ~50 C degrees C
• Weight: 201g (approx)

Features:

• Support computer operation interface settings
• Direction following  mode (PF)
• First-person mode (FPV)
• Built-in independent IMU module
• TAROT special PTZ servo drive module
• AV output interface
• Wide range voltage input support
• Support for conventional receiver /S-Bus receiver /DSM receiver
• Peripheral equipment:
• Support camera type: HERO3/HERO4 GOPRO and camera of the same size

Packge Included:

• 1 x Gimbal
• 1 x Control Module
• 1 x Connection Cable
• 1 x 5V Output AV Cable
• 1 x USB Module
• 1 x Flight Control Cable
