Arduino Leonardo R3 Compatible Board

Compared to other versions of the Arduino using a separate USB-Serial converter chip, the Leonardo innovatively uses a single-chip solution. Only with an Atmega32u4 USB communication and control. The Leonardo differs from all preceding boards in that the ATmega32u4 has built-in USB communication, eliminating the need for a secondary processor. This allows the Leonardo to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port. It also has other implications for the behavior of the board. Greatly improve the applications. Arduino Leonardo needs the new version above Arduino IDE1.01.

Specification:

Microcontroller ATmega32u4
Digital I / O pins20
Analog input channels12
PWM channels7
Flash memory 32KB of which 4KB used by the bootloader
SRAM 2.5KB
EEPROM 1KB
Clock speed 16MHz
DC current for 3.3V pin 50mA
DC current per I / O pin 40mA
Operating voltage5V
Input voltage7V-12V
Input voltage(limits) 6V-20V


Package included:

1 x Arduino compatible Leonardo R3
