10A Dual-Channel DC Motor Driver Module 3-18V - Forward/Reverse PWM & Dimming

This 10A Dual-Channel DC Motor Drive Module is a versatile H-bridge controller optimized for low-voltage, high-current scenarios such as robotics, model competitions, and automated systems. Operating between 3V and 18V, it supports independent bidirectional control of two DC motors or one 4-wire stepper motor. The module features low-internal resistance MOS tubes for high efficiency and minimal heat generation. With its 10A continuous output and integrated PWM support, it allows for smooth, stepless speed regulation and LED dimming. The signal terminals are compatible with standard 3.3V and 5V logic levels, ensuring easy integration with microcontrollers like Arduino or ESP32.

Key Features:

• High Current Capacity: Supports up to 10A continuous and 15A peak current per channel.
• Low Voltage Optimization: Functions reliably from 3V, perfect for single-cell Li-ion or NiMH battery packs.
• Bidirectional Control: Enables forward, reverse, and braking functionality for precise motion control.
• PWM Dimming Support: Can be used to control high-power LED strips or DC lamps.
• Thermal Efficiency: Designed with high-current MOS tubes that reduce the need for bulky heatsinks under 8A.

Package Includes:

1 x 10A Dual-Channel DC Motor Driver Module 3-18V - Forward/Reverse PWM & Dimming
