CY7C68013A-56LTXC EZ-USB FX2LP High-Speed USB Controller QFN-56

The CY7C68013A-56LTXC, part of the EZ-USB FX2LP™ family, is a highly integrated, low-power USB 2.0 microcontroller designed for high-performance peripheral applications. By combining a 48 MHz enhanced 8051 core with a high-speed USB 2.0 transceiver and a programmable peripheral interface (GPIF), Cypress has created a solution that allows for data transfer rates exceeding 53 Mbytes per second. The unique 'Soft Configuration' architecture enables firmware to be loaded directly into the 16 KB of on-chip RAM via USB or from an external EEPROM, providing unmatched design flexibility. This QFN-56 package version is ideal for bus-powered devices like logic analyzers, high-speed imaging systems, and custom data acquisition hardware where high bandwidth and a compact footprint are critical.

Features:

• High-Speed USB 2.0: Certified Hi-Speed transceiver with integrated Serial Interface Engine (SIE).
• Enhanced 8051 CPU: Runs at up to 48 MHz with 4 clocks per cycle, significantly faster than standard 8051 cores.
• General Programmable Interface (GPIF): Enables 'glueless' connection to DSPs, FPGAs, and parallel buses.
• Large On-Chip Memory: 16 KB of internal code/data RAM for flexible firmware execution.
• Integrated FIFOs: Four programmable FIFOs for high-efficiency data buffering and bus conversion.
• Ultra-Low Power: Designed for bus-powered applications with low suspend current (approx. 300 µA).

Package Includes:

1 x CY7C68013A-56LTXC EZ-USB FX2LP High-Speed USB Controller QFN-56
